这篇文章来看看 GD32 给我们提供的 gpio_af_set() 函数吧。该函数的功能是配置 GPIO的复用功能，如：可以配置某个IO位串口的Tx或Rx等。

函数实现

文件位置：gd32f1x0_gpio.c

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
/*!
    \brief      set GPIO alternate function
    \param[in]  gpio_periph: GPIOx(x = A,B,C,D,F)
                only one parameter can be selected which is shown as below:
      \arg        GPIOx(x = A,B,C,D,F)
    \param[in]  alt_func_num: GPIO pin af function, please refer to specific device datasheet
                only one parameter can be selected which is shown as below:
      \arg        GPIO_AF_0: TIMER2, TIMER13, TIMER14, TIMER16, SPI0, I2S0, SPI1, SPI2, I2S2, CK_OUT,
                             SWDIO, SWCLK, USART0, CEC, IFRP, I2C0, I2C1, TSI, EVENTOUT
      \arg        GPIO_AF_1: USART0, USART1, IFRP, CEC, TIMER2, TIMER14, I2C0, I2C1, I2C2, EVENTOUT
      \arg        GPIO_AF_2: TIMER0, TIMER1, TIMER15, TIMER16, EVENTOUT
      \arg        GPIO_AF_3: TSI, I2C0, TIMER14, EVENTOUT
      \arg        GPIO_AF_4(port A,B only): TIMER13, I2C0, I2C1, I2C2, USART1
      \arg        GPIO_AF_5(port A,B only): TIMER15, TIMER16, SPI2, I2S2, I2C0, I2C1
      \arg        GPIO_AF_6(port A,B only): SPI1, EVENTOUT
      \arg        GPIO_AF_7(port A only): CMP0, CMP1
      \arg        GPIO_AF_9(port A,B only): CAN0, CAN1 (only for GD32F170/F190 series)
      \arg        GPIO_AF_11: SLCD (only for GD32F170/F190 series)
    \param[in]  pin: GPIO pin
                one or more parameters can be selected which are shown as below:
      \arg        GPIO_PIN_x(x=0..15), GPIO_PIN_ALL
    \param[out] none
    \retval     none
*/
void gpio_af_set(uint32_t gpio_periph, uint32_t alt_func_num, uint32_t pin)
{
    uint16_t i;
    uint32_t afrl, afrh;

    afrl = GPIO_AFSEL0(gpio_periph);
    afrh = GPIO_AFSEL1(gpio_periph);

    for(i = 0U;i < 8U;i++){
        if((1U << i) & pin){
            /* clear the specified pin alternate function bits */
            afrl &= ~GPIO_AFR_MASK(i);
            afrl |= GPIO_AFR_SET(i,alt_func_num);
        }
    }

    for(i = 8U;i < 16U;i++){
        if((1U << i) & pin){
            /* clear the specified pin alternate function bits */
            afrh &= ~GPIO_AFR_MASK(i - 8U);
            afrh |= GPIO_AFR_SET(i - 8U,alt_func_num);
        }
    }

    GPIO_AFSEL0(gpio_periph) = afrl;
    GPIO_AFSEL1(gpio_periph) = afrh;
}

alt_func_num 参数

该参数用来指定 GPIO 的具体用作什么功能。

alt_func_num 功能
GPIO_AF_0 TIMER2, TIMER13, TIMER14, TIMER16, SPI0, I2S0, SPI1, SPI2, I2S2, CK_OUT, SWDIO, SWCLK, USART0, CEC, IFRP, I2C0, I2C1, TSI, EVENTOUT
GPIO_AF_1 USART0, USART1, IFRP, CEC, TIMER2, TIMER14, I2C0, I2C1, I2C2, EVENTOUT
GPIO_AF_2 TIMER0, TIMER1, TIMER15, TIMER16, EVENTOUT
GPIO_AF_3 TSI, I2C0, TIMER14, EVENTOUT
GPIO_AF_4(port A,B only) TIMER13, I2C0, I2C1, I2C2, USART1
GPIO_AF_5(port A,B only) TIMER15, TIMER16, SPI2, I2S2, I2C0, I2C1
GPIO_AF_6(port A,B only) SPI1, EVENTOUT
GPIO_AF_7(port A only) CMP0, CMP1
GPIO_AF_9(port A,B only) CAN0, CAN1 (only for GD32F170/F190 series)
GPIO_AF_11 SLCD (only for GD32F170/F190 series)
